Beam&Spot Moving Head

Beam 450W 3in1 Plus BSW CTO Hybrid Spot Wash Moving Head Light

Light Source: Roccer RSD 450W
Characteristic colors: 9 colors + linear CTO + white light
Fixed Gobo Wheel: 11 fixed patterns + 1 white light
Rotating Gobo wheel: 7 glass patterns + white light
Effect wheel: fog
Prism: a 3-facet prism and an 8-facet prism

Get A Quote
Please fill in your country or region so that a suitable business manager can contact you.
Quote / Inquiry / ask for assistance
Contact Us
Product Short information
Beam & Wash & Spot 3in1 450W Moving Head Light
Technical Specifications
Light source: Rccoer RSD 450W
Ballast: Electronic ballast
Color temperature: 7500K
Lamp life: 1500H
Power supply voltage: AC90-240V50/60Hz
Power consumption: 650W
Optical lens: anti-reflective coated glass lens
Focus: linear electronic focus
Dimming: 0-100% linear adjustment
Beam angle: 2.5-52 degrees
Color wheel: 9 colors + linear CTO + open
Fixed gobo wheel: 11 fixed gobos + open
Rotating gobo wheel: 7 glass gobos + open
Effect wheel: fog
Prism wheel: a 3-facet prism and an 8-facet prism
Strobe: 0-20 times/second
Motor: Three-phase motor fan with speed control board, which can effectively reduce noise and protect the light source, with integrated folding light hook
Control control signal: DMX512
Number of channels: 22CH
Control mode: International standard DMX512 control, master/slave mode, self-propelled mode, voice control mode, LCD liquid crystal display, DMX 3-core or 5-core signal input input/output Working environment working temperature
Cooling system: ultra-quiet fan
Waterproof grade: IP20
Packaging net weight: 18.8kg
Gross weight: 21kg
Packing size: 480*410*590mm
Accessories
Power Cable *1, DMX Cable *1, Quick Lock *1, Manual *1, Safety Cable *1
Exhibition
Lighting Factory

Manual

Item Download
Manual Beam 450W BSW 3IN1 User Manual
